Is is possible to update layers in AutoCAD automatically when we change unit type in column B? For example: Unit No. I also have an Excel spreadsheet that contains room number in column A (001, 002, 003,…, etc) and unit type in column B (Small Shop, Food, Hypermarket, Cinema, Department Store, etc). I have a plaza floor plan with each hatch for each unit (room) to represent unit type. I am now using AutoCAD 2013.Is it possible to change hatch layer via excel input through VBA or LISP? or maybe another method like MS Access etc. You can find it and all of my posts related to Microsoft Excel by clicking the Excel tag below. Update: If you found this post helpful, you might also be interested in my other post titled “ Quickly Link Excel Tables to AutoCAD “.

How to remove a datalink in cad for mac how to#

So there you have it, a quick run-through on how to harness the new Data Links in AutoCAD 2008. As a deliberate checks and balances, to update the Excel file, you must right-click once again, and select “Write Data Links to External Source“. To modify a table value in AutoCAD, select a cell, right-click, and navigate down to “Locking”, and select “Unlock”.Īfter unlocking a cell, you can click into a cell, change a value. By default however you will not be able to update data from AutoCAD, and have it update in the source Excel document.

Assuming you checked the “Retain Formulas” option when setting up the Data Link, you’ll notice fields (text with a grey background) for any calculated value.Īfter inserting your Excel table, any updates made in the source Excel file will be updated in AutoCAD.

You could close and re-open the drawing, but a little easier method is to select the table > right-click > “Update Table Data Links”.Press the button 3 times to get out of the command, and insert your linked table. AutoCAD will not update the table in real-time. Finally if you’re in a drawing, and the Excel document gets modified. In my humble opinion that method is a lot easier than unlocking the cell(s) you want to modify, changing the data, and then writing back to the data source. That will load Excel, and take you to the linked Excel document.

Under “ Data Links” select “ Open Data File“.

Select a cell within your AutoCAD Table.

This is relatively easy to do within AutoCAD by: Instead, I have found it easier to modify the Excel table by opening the Excel document itself.

While AutoCAD does have the ability to write back to Excel, I have found the methodology in doing such to be very cumbersome. Other information like the path to the linked Excel table and what cells are being displayed is among the data previewed. AutoCAD automatically generates a Data Link when you use the Paste Special method, hence the Excel Data Link 1 name. That is letting you know the table contents are being red from an external Excel table.įinally if you have dynamic input (DYN) turned on the southeast quadrant of your cursor will show some information about the data link associated with the table. The second icon is supposed to be two chain links. What that means is changes to the Excel document will be updated in AutoCAD as well, however you cannot make a change in AutoCAD and it update Excel. The padlock icon to the left indicates that the table is locked. If you have “DYN” turned on (available from status bar) you will see some helpful information when you hover over the table.įirst notice the two icons in the Northeast quadrant of your cursor. Select an insertion point for your table, and just like that you have a table which is linked to AutoCAD. From the resulting dialog box, Select the “ Paste Link” radio button, and then select “ AutoCAD Entities” under the “ As” heading.
